- GDZ-24-3
- ER20 CNC spindle motor
- 24000rpm CNC spindle
- 3kw spindle motor
- water-cooled spindle motors
- Φ105mm spindle motor
- CNC graving, milling spindle motor
- Three-bearing structure
- Our CNC spindle motors are supplied directly from the factory, not purchased from the lowest-priced suppliers with unknown sources, thus ensuring known quality and reliability. All CNC Router Spindles from RicoCNC are original, with No fake.
Technical Characteristics
| Type | GDZ-24-3 |
|---|---|
| Power | 2.2Kw |
| Voltage | 220V/380V |
| Current | 9A/5A |
| Frequency | 400Hz |
| Speed | 24000rpm |
| Weight | 8.5KG |
| Bearing | 2x7005C, 1x7003C |
| Collet | ER20 |
Spindle Design
- GDZ-24-3 provides two voltage options, 220V and 380V, to meet different industrial power requirements. With excellent quality control and high quality, it is very suitable for industrial applications that require high-speed and high-precision processing.
