- GDZ65F-800
- ER11 spindle motor
- 24000rpm CNC spindle
- 800w air-cooled spindle motor
- 220V electro spindle motor
- CNC milling, graving spindle motor
- Φ65mm spindle motor
- round air-cooling spindle
- Our CNC spindle motors are supplied directly from the factory, not purchased from the lowest-priced suppliers with unknown sources, thus ensuring known quality and reliability. All CNC Router Spindles from RicoCNC are original, with No fake.
Technical Characteristics
| Spindle Type | GDZ65F-800 |
|---|---|
| Diameter | Φ65mm |
| Speed | 24000rpm |
| Power | 0.8kw |
| Voltage | 220V |
| Current | 4A |
| Frequency | 400HZ |
| Torque | 0.33Nm |
| Collet | ER11 |
| bearing type | 7002CP4*2+7000CP4*2 |
| Weight | 2.5KG |
Spindle Design
- GDZ65F-800, with a diameter of 65mm, is suitable for compact equipment and precision processing. The speed of 24000rpm ensures processing efficiency and precision. It is suitable for small CNC machine tools, precision engraving machines, dental equipment, jewellery processing, watch manufacturing, electronic component processing, etc., especially for occasions requiring high-speed and precision processing.
